Melting Furnace
Induction Melting Furnace
>> Fast and wide heating
>> Comprehensive protection
>> Easy installation and operation
>> High effectiveness
>> Small size and light weight
>> Elimination of high voltage
Description
Induction melting furnace is widely used for platinum, palladium, rhodium, gold, silver, copper, steel, alumunum, carbon, gold dust, sands, electrolytic mud, gold and silver power, and other metals.
There are cabinet type, portable type, auto-tilting type, and simple type.
Model 15A to 45AB: there are cabinet type and portable type for option;
Model 60AB to 120AB: there are tilting type and simple type for option.
Power
1) Induction heating: mainly through the crucible. to precious metal in an instant , then smelting .refining ,casting and other processes:
2) A single molten metal quantity:1kg-50kg.a single melting time:2-20 minutes:
3) The maximum furnace temperature up to 1500-2000 degrees.
Technical specification
|
Model |
15A |
25A |
35AB |
45AB |
60AB |
80AB |
100AB |
120AB |
|
Power |
2kw |
5kw |
10kw |
15kw |
20kw |
30kw |
45kw |
70kw |
|
Power Source |
220V |
380V |
380V |
380V |
380V |
380V |
380V |
380V |
|
High Frequency |
30~50KHZ |
|||||||
|
Middle Frequency |
1~15KHZ |
|||||||
|
Content of Metal Smelting |
1~2kg |
1~4kg |
1~8kg |
1~15kg |
1~25kg |
1~40kg |
1~50kg |
1~100kg |
|
Processing Time |
≤5Min |
≤5Min |
≤10Min |
≤15Min |
≤20Min |
≤30Min |
≤40Min |
≤40Min |
